Standard Conformity | IS/IEC 60947-3 |
Rated Current (In) | 40-63-100 |
Rated Voltage (AC) (Ue) | 240 / 415 V |
Rated Frequency (F) | 50 Hz |
Nos. of Poles | 1P, 2P, 3P, 4P |
Rated Insulation Voltage (Ui) V | 660 |
Rated Impulse Voltage (Uimp) kV | 6 |
Electrical / Mechanical Endurance | |
(No. of operations) | 10,000 |
Ambient Temperature (0C) | +5 to +55 |
Terminal Capacity (max) Sq. mm | 25 |
Vibration g | 5 |
Shock | 40 mm free fall |
Protection Class | IP 20 |
Installation Position | Vertical / Horizontal |
Mounting | on Din Rail (35 mmx 7.5 mm) |
Housing | Moulded Flame Retardent Thermoplastic Material |
